0-22”X-Proof刻度盘深度计

描述

福勒52-125-007-0 0 ?22”Dial Depth Gages comes with six interchangeable rods with a 0—22" capacity, carbide contact point and 2 extra points for small applications. Provides rapid measurement of hole depths.X-Proof Special Features:• Coolant, fluid and dust resistant to IP54 Specifications.• Sealed bezel, top cap and dial with bellows on stem• Sealed back plateOther Features:• Measurements automatically registered directly on dial face in .001" graduations. The dial indicator can be easily adjusted for zero setting.• Graduation: .001"• 0-1" travel indicator• Accuracy of the dial indicator meets Federal specifications• Rod extensions of 1", 2", 3", 4", 5" and 6" are included. Rods can be connected together for a full 0—22" capacity.• Includes 2 extra points for small hole applications; one 0.078" dia. x 1" long and one needle point x 1" long.• Base is hardened steel, ground and microlapped for accuracy• Standard 4-48 thread removable carbide ball contact point• Rack spindle and pinions are hardened stainless steel to ensure long wear and continuing accuracy.• Includes shop hardened case
